AXIS M3077-PLVE M39 Series 6MP Outdoor Vandal Resistant 360° Panoramic Fixed Dome IR WDR IP Camera, 1.56mm Lens, White
M3077|Z4-02018001
AXIS M3077-PLVE M39 Series 6MP Outdoor Vandal Resistant 360° Panoramic Fixed Dome IR WDR IP Camera, 1.56mm Lens, White
M3077|Z4-02018001
Key Features
What's Included
- Built-in microphones
- Complete 180° and 360° overview
- Digital PTZ and dewarped views
Key Features
What's Included
- Built-in microphones
- Complete 180° and 360° overview
- Digital PTZ and dewarped views
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
What's Included
- Built-in microphones
- Complete 180° and 360° overview
- Digital PTZ and dewarped views
Axis Communications
AXIS M3077-PLVE M39 Series 6MP Outdoor Vandal Resistant 360° Panoramic Fixed Dome IR WDR IP Camera, 1.56mm Lens, White
M3077 | Z4-02018001
Please sign in to view pricing and availability and to add to cart.
Accessories
Video Surveillance Monitors
ADI # 0E-20LED2
MODEL # 0E-20LED2
0E-20LED2|0E-20LED2
Sign In for Dealer Pricing
Power Conditioners
ADI # WT-WB700IP12
MODEL # WT-WB700IP12
WT-WB700IP12|WT-WB700IP12
Sign In for Dealer Pricing
Power Conditioners
ADI # WT-WB800IP12
MODEL # WT-WB800IP12
WT-WB800IP12|WT-WB800IP12
Sign In for Dealer Pricing
Overview
Specifications
Documents
Product Overview
With its 6 MP sensor, AXIS M3077-PLVE offers excellent image quality and a complete 180° or 360° overview, indoors or out, around the clock. It features two built-in microphones allowing for audio surveillance and detection. This compact mini dome offers dewarped views such as panorama, quad, corner, and corridor views directly from the camera. It includes Axis Lightfinder and Axis Forensic WDR for true colors and great details in challenging light or near darkness. And, Axis OptimizedIR for surveillance in pitch darkness.
Main Features
- Built-in microphones
- Complete 180° and 360° overview
- Digital PTZ and dewarped views
- Enhanced security features
- Lightfinder, Forensic WDR and Optimized IR
General Information
Name: AXIS M3077-PLVE M39 Series 6MP Outdoor Vandal Resistant 360° Panoramic Fixed Dome IR WDR IP Camera, 1.56mm Lens, White
Category: Axis Communications, Video Surveillance, IP Cameras, Panoramic Cameras
UPC Code: 7331021070813
Country of Origin: Thailand. Country of origin is subject to change.
Specifications
-
ADI Part Number Z4-02018001 Brand Name AXIS Communications Manufacturer Axis Communications Manufacturer Part Number 02018-001 Product Line M Product Model M3077 Product Name AXIS M3077-PLVE Product Series M30 Product Type Fixed dome cameras Supported Network Protocols IPv6 USGv6|NIST SP500-267 Weight 1.54 lb
-
Aperture f/2.0 Built-in Microphone Yes Connectivity Technology Wired Effective Camera Resolution 6MP Field of View Horizontal, Vertical Lens Type Fixed Maximum Aperture f/2 Maximum Frame Rate 60 fps Minimum Focal Length 1.56 mm Night Vision Yes Night Vision Type Infrared Video Formats H.264, H.265, MJPEG, MPEG-4
-
Image Sensor Type CMOS Night Vision Distance 65.62 ft Wide Dynamic Range Yes
-
Ingress Protection Rating IP66 NDAA Compliant Yes
-
Image Sensor Size 1/1.8" Maximum Video Resolution 2016 x 2016
-
Maximum Operating Temperature 122°F (50°C) Minimum Operating Temperature -40°F (-40°C) Operating Humidity 100% Operating Temperature (T-T) -40-50°C
-
Longest Shutter Speed 1 Second Minimum Illumination 0 lux Shortest Shutter Speed 1/16000 Second
-
Network (RJ-45) Yes
-
Focal Length 1.56mm Lens Included Yes Maximum Focal Length 1.56 mm
-
Memory Card Supported Yes
-
Remote Management Yes
-
ADI Part Number Replaces Z4-0548001 Model Number Replaces 0548-001
-
Color White Durability Vandal Resistant Form Factor Dome Height 2.6"
-
Maximum Power Consumption 12W Power over Ethernet (PoE) Yes
-
Diameter 5.9" Mount Type Ceiling Mount, Conduit Mount, Corner Mount, Pendant Mount, Pole Mount, Surface Mount, Wall Mount
-
Storage Type Memory Card
-
Maximum Resolution 1280 x 720
-
Limited Warranty 5-Year
-
Certifications CISPR 35, EAC, EN 55024, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A Certifications & Standards ONVIF G, ONVIF M, ONVIF S, ONVIF T Country of Origin TH Environmental Certification IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 60721-3-5 Class 5M3, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9) Features Audio Detection, Auto Gain Control, Automatic White Balance, Built-in IR LED, Built-in Microphone, Day/Night, Motion Detection, Multi-view Stream, Noise Reduction, Privacy Masking, PTZ, Removable IR Cut-off Filter, SD Card Local Storage, Tampering Alarm, Video Management System, Wide Dynamic Range Impact Protection Rating IK08 Indoor/Outdoor Outdoor Package Contents - M3077-PLVE Network Camera
- Installation Guide
- Windows Decoder 1-user license
- Drill Hole Template
- Cable Gaskets
- Connector Guard
- I/O Connector
- RESISTORX TR20 bit
- and more below
