Belden 1585A 009U1000 CAT5e Plenum Cable, 24/4 Solid BC, Unshielded, UTP, CMP, 1000' (304.8m) Reel, White
1585A 009U1000
|7B-1585A009U
Color: White
Cable Length: 1000'
Jacket Type: Plenum
Shop All Belden
Belden 1585A 009U1000 CAT5e Plenum Cable, 24/4 Solid BC, Unshielded, UTP, CMP, 1000' (304.8m) Reel, White
1585A 009U1000 | 7B-1585A009U
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The Belden 1585A 009U1000 is a high-performance CAT5e plenum cable designed for reliable network connections. Featuring a 24/4 solid bare copper design and unshielded twisted pairs, this cable ensures efficient data transmission on a 1000' reel. Key benefits include reduced near-end crosstalk, enhanced attenuation to crosstalk ratios, and superior bendability for flexible installations. Compatible with PoE++, PoE+, and PoE, it supports power-over-Ethernet devices smoothly. Ideal for professional setups, this cable combines durability with advanced signal integrity. Upgrade your network today with Belden’s trusted quality!
Specifications
ADI Part Number 7B-1585A009U Brand Name Belden Manufacturer Belden CDT, Inc Manufacturer Part Number 1585A 009U1000 Product Name Category 5e Cable, 4 Pair, U/UTP, CMP Product Type Network Cable
American Wire Gauge 24AWG Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE, PoE+, PoE++, Premise Horizontal Cable Cable Rating Plenum Cable Type Category 5e Conductor Count 8 Conductor Material Bare Copper Device Supported Network Device Jacket Material PVC Jacket Type Plenum Material Copper Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded Solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Data Transfer Rate 10 Gbit/s
Cable Length 1000' Color White Insulation Material FEP
Environmental Certification China RoHS 2, EU RoHS, EU WEEE, REACH, RoHS 2 Environmentally Friendly Yes Features Attenuation Crosstalk Ratio Far-end (ACR-F), Attenuation to Crosstalk Ratio (ACR), Bendable, Equal Level Far End Crosstalk (ELFEXT), Minimized Near-End Crosstalk (NEXT), PoE, PoE+, PoE++, Power Sum Attenuation to Crosstalk Ratio (PSACR), Power Sum Attenuation to Crosstalk Ratio, Far-End (PSACRF), Power-sum Equal Level Far-End Crosstalk (PSELFEXT), Power-sum Near End Crosstalk (PSNEXT), Stranded Indoor/Outdoor Indoor
