Belden 2413 004A1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, Yellow, Reel-in-Box, 1,000'
2413 004A1000
|7B-2413004A1
Color: Yellow
Shielding: No
Number of Conductors: 8
Shop All Belden
Belden 2413 004A1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, Yellow, Reel-in-Box, 1,000'
2413 004A1000 | 7B-2413004A1
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
Category 6+ Enhanced Premise Horizontal Cable (350MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest® PVC-LS Jacket
Main Features
- 4 Pair, 23 AWG Solid Bare Copper Conductors
- Premise Horizontal Cable
- PO and FEP - Polyolefin and Fluorinated Ethylene Propylene Insulation
- Flamarrest PVC Jacket
- 300 V (CMP), 300 V (CL3P) UL Voltage Rating
- Plenum, Indoor
- NFPA 262, UL 910 (Plenum), FT6, IEC 60332-1-2
- Article 800, CMP, CMP-LP (0.5A), CL3P-LP (0.5A)
- Category 6
- Suitable Applications: Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE++, PoE+, PoE
General Information
Name: Belden 2413 004A1000 Category 6+ Enhanced Premise Horizontal Cable 350MHz, 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest PVC-LS Jacket, Yellow, Reel-in-Box, 1,000'
Category: Belden, Wire & Cable, Network Cables, Category 6 Network Cables
UPC Code: 612825061649
Country of Origin: Mexico. Country of origin is subject to change.
Specifications
ADI Part Number 7B-2413004A1 Brand Name Belden Manufacturer Belden CDT, Inc Manufacturer Part Number 2413 004A 1000 Product Name Category 6+ Enhanced Cable, 4 Pair, U/UTP, CMP Product Type Network Cable
American Wire Gauge 23AWG Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE, PoE+, PoE++, Premise Horizontal Cable Cable Rating Plenum Cable Type Category 6 Conductor Count 4 Conductor Material Bare Copper Device Supported Network Device Jacket Material PVC Jacket Type CMP, Plenum Material Bare Copper, PVC Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded Solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Data Transfer Rate 1 Gbit/s
Cable Length 1000' Color Yellow Package Type Reel-in-Box Weight 26 lb
Country of Origin MX Environmental Certification CEC, China RoHS 2, EU RoHS, EU WEEE, REACH, RoHS 2 Features Attenuation Crosstalk Ratio Far-end (ACR-F), Bendable, Equal Level Far End Crosstalk (ELFEXT), Minimized Near-End Crosstalk (NEXT), PoE, PoE+, PoE++, Power Sum Attenuation to Crosstalk Ratio, Far-End (PSACRF), Power-sum Near End Crosstalk (PSNEXT), Stranded Indoor/Outdoor Indoor
