Belden 2413 008A1000 CAT6 Plus Plenum Cable, 23/4 Solid BC, Unshielded, UTP, CMP, FT6, 1000' (304.8m) Reel-in-Box, Gray
2413 008A1000|7B-2413008A1
Color: Gray
Shielding: No
Number of Conductors: 8
Belden 2413 008A1000 CAT6 Plus Plenum Cable, 23/4 Solid BC, Unshielded, UTP, CMP, FT6, 1000' (304.8m) Reel-in-Box, Gray
2413 008A1000|7B-2413008A1
Color: Gray
Shielding: No
Number of Conductors: 8
Key Features
- Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE , PoE , PoE Solid Stranding Conductor Material: Bare Copper
- Number of Pairs: 4
- Size 23 AWG
Key Features
- Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE , PoE , PoE Solid Stranding Conductor Material: Bare Copper
- Number of Pairs: 4
- Size 23 AWG
.jpg)
Key Features
- Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE , PoE , PoE Solid Stranding Conductor Material: Bare Copper
- Number of Pairs: 4
- Size 23 AWG
Belden
Belden 2413 008A1000 CAT6 Plus Plenum Cable, 23/4 Solid BC, Unshielded, UTP, CMP, FT6, 1000' (304.8m) Reel-in-Box, Gray
2413 008A1000 | 7B-2413008A1
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Category 6+ Enhanced Premise Horizontal Cable (350MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Plenum-CMP, Flamarrest® PVC-LS Jacket
Main Features
- Premise Horizontal Cable, Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE , PoE , PoE Solid Stranding Conductor Material: Bare Copper
- Number of Pairs: 4
- Size 23 AWG
- Stranding: Solid
- Material: BC - Bare Copper (High Conductivity)
- Insulation Material: PO FEP - Polyolefin Fluorinated Ethylene Propylene
- Plenum
- Experience a simpler way to connect devices with the entire business network
- Features Category 6+ cable type for your convenience and desired usability
- PoE++ feature for your convenience and ease of usage
General Information
Name: Belden 2413 008A1000 CAT6 Plus Plenum Cable, 23/4 Solid BC, Unshielded, UTP, CMP, FT6, 1000' (304.8m) Reel-in-Box, Gray
Category: Belden, Wire & Cable, Network Cables, Category 6 Network Cables
UPC Code: 612825061724
Country of Origin: Mexico. Country of origin is subject to change.
Specifications
-
ADI Part Number 7B-2413008A1 Brand Name Belden Manufacturer Belden CDT, Inc Manufacturer Part Number 2413008A1000 Product Name Category 6+ Enhanced Cable, 4 Pair, U/UTP, CMP Product Type Network Cable
-
American Wire Gauge 23AWG Cable Rating Riser Cable Type Category 6a Conductor Count 4 Conductor Material Bare Copper Device Supported Network Device Jacket Material PVC Jacket Type Plenum Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded Solid
-
Data Transfer Rate 1 Gbit/s
-
Cable Length 1000' Color Gray Insulation Material FEP Material Bare Copper, PVC Package Type Bulk
-
Country of Origin MX Environmental Certification CEC, China RoHS 2, EU RoHS, EU WEEE, REACH, RoHS 2 Environmentally Friendly Yes Features Attenuation to Crosstalk Ratio (ACR), Bendable, Equal Level Far End Crosstalk (ELFEXT), Minimized Near-End Crosstalk (NEXT), PoE, PoE+, PoE++, Power Sum Attenuation to Crosstalk Ratio (PSACR), Power-sum Equal Level Far-End Crosstalk (PSELFEXT), Power-sum Near End Crosstalk (PSNEXT), Stranded
