Belden 1583A 010U1000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' UnReel, Black
1583A 010U1000
|7B-1583100BK
Shop All Belden
Belden 1583A 010U1000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' UnReel, Black
1583A 010U1000 | 7B-1583100BK
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
DataConnect Category 5e Premise Horizontal Cable (200MHz), 4 Pair, 24 AWG Solid Bare Copper Conductors, U/UTP, Riser-CMR, PVC Jacket. Ensure maximum network performance and stability in legacy IP applications, renovations and price-sensitive environments with Category 5e cables that exceed standards. Belden offers several Category 5e performance levels. Our top-of-line 1200 Series cable provides headroom beyond the TIA-568-C.2 Category 5e standard and is offered with Bonded-Pair technology to make your installation as robust as possible.
Main Features
- Category 5e Premise Horizontal Cable (200MHz)
- 4 Pair, 24 AWG Solid Bare Copper Conductors
- Unshielded/Unshielded Twisted Pair (U/UTP)
- PO - Polyolefin Insulation
- PVC Jacket
- Indoor
- 300 V (CMR)
- 25 lbs (11 kg) Max. Pull Tension
- 75°C UL Temperature
- China RoHS II (GB/T 26572-2011)
General Information
Name: Belden 1583A 010U1000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' UnReel, Black
Category: Belden, Wire & Cable, Network Cables, Category 5e Network Cables
UPC Code: 612825118145
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-1583100BK Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE, PoE+, PoE++, Premise Horizontal Cable Brand Name Belden Country of Origin MX Manufacturer Part Number 1583A 010U1000 Packaged Quantity 305 Product Line DataConnect
American Wire Gauge 24AWG Cable Rating Riser Cable Type Category 5e Conductor Count 8 Conductor Material Bare Copper Fiber Category OM3 Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Cable Length 1000' Color Black Insulation Material PE, PO, PP Jacket Material PVC
Voltage Rating 300V RMS
Length 1000.0'
Indoor/Outdoor Indoor
