Belden 1583A 0091000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' Reel, White
1583A 0091000
|7B-1583A0091
Shop All Belden
Belden 1583A 0091000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' Reel, White
1583A 0091000 | 7B-1583A0091
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
DataConnect Category 5e Premise Horizontal Cable (200MHz), 4 Pair, 24 AWG Solid Bare Copper Conductors, U/UTP, Riser-CMR, PVC Jacket. Ensure maximum network performance and stability in legacy IP applications, renovations and price-sensitive environments with Category 5e cables that exceed standards. Belden offers several Category 5e performance levels. Our top-of-line 1200 Series cable provides headroom beyond the TIA-568-C.2 Category 5e standard and is offered with Bonded-Pair technology to make your installation as robust as possible.
Main Features
- Category 5e Premise Horizontal Cable (200MHz)
- 4 Pair, 24 AWG Solid Bare Copper Conductors
- Unshielded/Unshielded Twisted Pair (U/UTP)
- PO - Polyolefin Insulation
- PVC Jacket
- Indoor
- 300 V (CMR)
- 25 lbs (11 kg) Max. Pull Tension
- 75°C UL Temperature
- China RoHS II (GB/T 26572-2011)
General Information
Name: Belden 1583A 0091000 CAT5e 24/4 Riser Premise Horizontal Cable, 200MHz, U/UTP, Solid BC, PVC Jacket, 1000' Reel, White
Category: Belden, Wire & Cable, Network Cables, Category 5e Network Cables
UPC Code: 612825118107
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number 7B-1583A0091 Application/Usage Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE, PoE+, PoE++, Premise Horizontal Cable Brand Name Belden Country of Origin MX Manufacturer Part Number 1583A 0091000 Package Type Reel/Spool Packaged Quantity 305 Product Line DataConnect
American Wire Gauge 24AWG Cable Rating Riser Cable Type Category 5e Conductor Count 8 Conductor Material Bare Copper Number of Conductors 8 Number of Pairs 4 Shielding No Solid or Stranded Solid
Operating Temperature (T-T) -20-75°C Storage Temperature (T-T) -20-75°C
Cable Length 1000' Color White Insulation Material PE, PO, PP Jacket Material PVC
Voltage Rating 300V RMS
Indoor/Outdoor Indoor
