Leviton 15R21-UR 15 Series 8-2AWG Taper Nose Cam-Type Male Panel Mount Receptacle, 0.5" Threaded Stud, Pink
15R21-UR
|LV-15R21UR
Shop All Leviton
Leviton 15R21-UR 15 Series 8-2AWG Taper Nose Cam-Type Male Panel Mount Receptacle, 0.5" Threaded Stud, Pink
15R21-UR | LV-15R21UR
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
15 Series Cam-Type Male Panel Mount Receptacle, 0.5" Threaded Stud Termination, 90-Degree, #8 - #2 AWG, 150 Amp Max, Type 3R When Mated, Red Leviton's Rhino-Hide Single Pole Cam-Type Connectors supply temporary electrical power for both indoor and outdoor applications. These devices are designed for easy assembly and disassembly, without special tools.
NEMA 3R rated for outdoor use when mated
UL: 1691, 508 - 35k A / 600V Short Circuit Current Rating
Color-coding provides fast and easy phase identification
Common applications: entertainment, oil and gas, mining operations, power distribution, construction sites, and other temporary power applications
NEMA 3R rated for outdoor use when mated
UL: 1691, 508 - 35k A / 600V Short Circuit Current Rating
Color-coding provides fast and easy phase identification
Common applications: entertainment, oil and gas, mining operations, power distribution, construction sites, and other temporary power applications
Main Features
- 15 Series Cam-Type Male Panel Mount Receptacle
- 0.5" Threaded Stud Termination
- 90-Degree Design for Versatile Use
- #8 - #2 AWG Compatibility
- 150 Amp Maximum Capacity
- Type 3R Rated for Outdoor Use
- Easy Assembly and Disassembly
- UL 1691, 508 Certified
- Color-Coded for Phase Identification
- Ideal for Temporary Power Applications
General Information
Name: Leviton 15R21-UR 15 Series 8-2AWG Taper Nose Cam-Type Male Panel Mount Receptacle, 0.5" Threaded Stud, Pink
Category: Leviton, Batteries & Power Supplies, Electrical Cords & Connectors, Power Plugs
UPC Code: 78477709900
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number LV-15R21UR Brand Name Leviton Country of Origin MX Manufacturer Leviton Mfg. Company, Inc Manufacturer Part Number 15R21-UR Product Name Male Panel Mount Receptacle, #8 - #2 AWG, 0.5" Threaded Stud Termination Product Series 15 Product Type Power Socket
CSA Listed Yes RoHS Compliant Compliant
Color Red
Voltage Rating 600V
Limited Warranty 2-Year
