Product Overview
30A, 480V 3-Phase, NEMA L16-30P, 3P, 4W, Locking Plug, Industrial Grade, Grounding, Wetguard, Yellow.
Main Features
- Battle the Elements; Resistant to water, acids, alkalies, and many automotive and industrial lubricants and solvents
- Watertight; When mated or caps are on, feature IP69K ratings for high-temperature, high-pressure washdowns
- Unique Design; Exclusive 'tongue and groove' design provides superior ingress protection from water, dirt and debris
- High Performance; Heavy-duty, one-piece contacts for maximum conductivity electrical performance
General Information
Name: Leviton 28W76 Wetguard Watertight Locking Plug, Black
Category: Leviton, Batteries & Power Supplies, Electrical Cords & Connectors, Power Connectors
UPC Code:
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number LV-28W76 Brand Name Leviton Country of Origin MX Manufacturer Part Number 28W76 Product Name Wetguard Watertight Locking Plug Product Type Plug
American Wire Gauge 10AWG, 4AWG Contact Plating Nickel
Ingress Protection Rating IP66, IP67, IP69K RoHS Compliant Compliant
Operating Temperature (T-T) -40°C to 60°C
Color Yellow Material Rubber, Brass
Current Rating 30.00A Voltage Rating 480V AC
Limited Warranty Limited Lifetime
Environmental Certification CSA, UL Environmentally Friendly Yes
