Panduit LAA2-38-70 Compression Connector Lug, 1-Hole, 2AWG, Aluminum
LAA2-38-70
|P9-LAA23870
Shop All Panduit
Panduit LAA2-38-70 Compression Connector Lug, 1-Hole, 2AWG, Aluminum
LAA2-38-70 | P9-LAA23870
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The LAA2-38-70 Aluminum Compression Connector Lug, one hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound and tin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90°C.
Main Features
- High conductivity thick wall aluminum construction
- One-hole design for secure connection
- Enclosed barrel suitable for harsh environments
- Color-coded barrels for proper crimp die selection
- Factory pre-filled with joint compound
- Tin-plated to inhibit corrosion
- cULus listed up to 35kV voltage rating
- Temperature rated to 90°C
General Information
Name: Panduit LAA2-38-70 Compression Connector Lug, 1-Hole, 2AWG, Aluminum
Category: Panduit, Batteries & Power Supplies, Power Accessories & Parts
UPC Code: 613056857803
Country of Origin: . Country of origin is subject to change.
Specifications
ADI Part Number P9-LAA23870 Brand Name Panduit Manufacturer Part Number LAA2-38-70
American Wire Gauge 2AWG
Length 2.6"
