Genesis 43085504 18/6 Solid Unshielded Fire Alarm Cable, Riser, FPLR, 500' (152.4 m) Pull Box, Red
43085504|WG-43085504
Color: Red
Cable Length: 500'
Package Type: Pull Box
Number of Conductors: 6
American Wire Gauge: 18AWG
Genesis 43085504 18/6 Solid Unshielded Fire Alarm Cable, Riser, FPLR, 500' (152.4 m) Pull Box, Red
43085504|WG-43085504
Color: Red
Cable Length: 500'
Package Type: Pull Box
Number of Conductors: 6
American Wire Gauge: 18AWG
Key Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- Polypropylene insulation
- PVC jacket
Key Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- Polypropylene insulation
- PVC jacket
Key Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- Polypropylene insulation
- PVC jacket
Genesis
Genesis 43085504 18/6 Solid Unshielded Fire Alarm Cable, Riser, FPLR, 500' (152.4 m) Pull Box, Red
43085504 | WG-43085504
Please sign in to view pricing and availability and to add to cart.
Recommended
P2RLED | BK-P2RLED
P2RLED | BK-P2RLED
Sign In for Dealer Pricing
PC2RLED | BK-PC2RLED
PC2RLED | BK-PC2RLED
Sign In for Dealer Pricing
SRLED | BK-SRLED
SRLED | BK-SRLED
Sign In for Dealer Pricing
BG-12 | FL-BG12
BG-12 | FL-BG12
Sign In for Dealer Pricing
45061006 | WG-45061006
45061006 | WG-45061006
Sign In for Dealer Pricing
Overview
Specifications
Documents
Product Overview
Genesis Fire Alarm Cables ensure uninterrupted fire protection. Built to exceed the demands of rigorous fire safety codes and regulations, UL listed, and Made in the USA.
Main Features
- Bare Copper conductors for excellent conductivity and low voltage drop
- Polypropylene insulation
- PVC jacket
- Durable rip cord for efficient jacket stripping and removal
- Countdown Length Markings for easy tracking of usage and remaining cable
- Rated for 300 Volts
- Rated for -20 °C to 75 °C
- Sunlight Resistant (UV) Rated
- REACH/RoHS Compliant
General Information
Name: Genesis 43085504 18/6 Solid Unshielded Fire Alarm Cable, Riser, FPLR, 500' (152.4 m) Pull Box, Red
Category: Genesis, Wire & Cable, Fire & Life Safety Cables, Non-Plenum Unshielded Cables
UPC Code: 194160006894
Country of Origin: United States. Country of origin is subject to change.
Specifications
-
ADI Part Number WG-43085504 Brand Name Genesis Manufacturer Genesis Cable Manufacturer Part Number 43085504 Packaged Quantity 1 Product Model 43085504 Product Name 18 AWG 6 Solid Conductors, Riser FPLR Product Type Fire Alarm Cable Weight 12.80 lb
-
American Wire Gauge 18AWG Cable Rating Riser Conductor Count 6 Conductor Material Bare Copper Connector on First End Bare Wire Connector on Second End Bare Wire Core/Cladding Diameter 18/6 Device Supported Fire Alarm Jacket Material PVC Jacket Type Plenum Number of Conductors 6 Number of Pairs 1 Shielding No Solid or Stranded Solid
-
TAA Compliant Yes
-
Cable Length 500' Color Red Insulation Material PP Material Bare Copper Package Type Pull Box
-
Limited Warranty 3-Year
-
Country of Origin US Environmental Certification RoHS Environmentally Friendly Yes Features Stranded Indoor/Outdoor Indoor
