Genesis 50075508 RG6 CCS 75 Ohm Coaxial with Quad-Shield Cable, General Purpose, CATV, 500' (152.4 m) Pull Box, Black
50075508|WG-50075508
Color: Black
Cable Length: 500'
Package Type: Pull Box
Genesis 50075508 RG6 CCS 75 Ohm Coaxial with Quad-Shield Cable, General Purpose, CATV, 500' (152.4 m) Pull Box, Black
50075508|WG-50075508
Color: Black
Cable Length: 500'
Package Type: Pull Box
Key Features
- Solid Copper Clad Steel center conductor for excellent transmission up to 3 GHz
- Polyethylene insulation
- Quad-shielded (Aluminum Foil + Aluminum Braid + Aluminum Foil + Braid)
Key Features
- Solid Copper Clad Steel center conductor for excellent transmission up to 3 GHz
- Polyethylene insulation
- Quad-shielded (Aluminum Foil + Aluminum Braid + Aluminum Foil + Braid)
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- Solid Copper Clad Steel center conductor for excellent transmission up to 3 GHz
- Polyethylene insulation
- Quad-shielded (Aluminum Foil + Aluminum Braid + Aluminum Foil + Braid)
Genesis
Genesis 50075508 RG6 CCS 75 Ohm Coaxial with Quad-Shield Cable, General Purpose, CATV, 500' (152.4 m) Pull Box, Black
50075508 | WG-50075508
Please sign in to view pricing and availability and to add to cart.
Overview
Specifications
Documents
Product Overview
Genesis Broadband CATV Coaxial Cables deliver exceptional signal quality and protect from interference for satellite, cable, and broadcast TV applications.
Main Features
- Solid Copper Clad Steel center conductor for excellent transmission up to 3 GHz
- Polyethylene insulation
- Quad-shielded (Aluminum Foil + Aluminum Braid + Aluminum Foil + Braid)
- PVC jacket
- Countdown Length Markings for easy tracking of usage and remaining cable
- Rated for 300 Volts
- Rated for -20 °C to 75 °C
- Sunlight Resistant (UV) Rated
- REACH/RoHS Compliant
General Information
Name: Genesis 50075508 RG6 CCS 75 Ohm Coaxial with Quad-Shield Cable, General Purpose, CATV, 500' (152.4 m) Pull Box, Black
Category: Genesis, Wire & Cable, Coaxial Cables
UPC Code: 619172042680
Country of Origin: China. Country of origin is subject to change.
Specifications
-
ADI Part Number WG-50075508 Brand Name Genesis Manufacturer Genesis Cable Manufacturer Part Number 50075508 Packaged Quantity 1 Product Model 50075508 Product Name 50075508 Coaxial Antenna Cable Product Type Coaxial Cable Weight 17.70 lb
-
American Wire Gauge 18AWG Cable Rating General Purpose Cable Type RG-6 Conductor Count 1 Conductor Material CCS Impedance 75 ohms Jacket Material PVC Jacket Type General Purpose Number of Conductors 1 Shielding Yes Solid or Stranded Solid
-
TAA Compliant No
-
ADI Part Number Replaces WG-50076108 Model Number Replaces 50076108
-
Cable Length 500' Color Black Insulation Material PE Material Copper Clad Steel Package Type Pull Box
-
Limited Warranty 3-Year
-
Country of Origin CN Environmental Certification RoHS Environmentally Friendly Yes Features Stranded Indoor/Outdoor Indoor
