GRI 29PD-B 29P Series Standard Surface Mount Magnetic Reed Switch Set, Standard Gap, DPDT, CX2, Brown
29PD-B|GI-29PDB
Color: Brown
Standard Gap: 1"
GRI 29PD-B 29P Series Standard Surface Mount Magnetic Reed Switch Set, Standard Gap, DPDT, CX2, Brown
29PD-B|GI-29PDB
Color: Brown
Standard Gap: 1"
Key Features
- This Versatile Series Sets The Industry Standard For Co mmercial and Light Industrial Applications
- Surface Mount Magnetic Contacts
- 24" #22 AWG 2 Conductor Jacketed Lead on 29PA
Key Features
- This Versatile Series Sets The Industry Standard For Co mmercial and Light Industrial Applications
- Surface Mount Magnetic Contacts
- 24" #22 AWG 2 Conductor Jacketed Lead on 29PA
Sign In for Dealer Pricing
Become an ADI CustomerKey Features
- This Versatile Series Sets The Industry Standard For Co mmercial and Light Industrial Applications
- Surface Mount Magnetic Contacts
- 24" #22 AWG 2 Conductor Jacketed Lead on 29PA
George Risk Industries
GRI 29PD-B 29P Series Standard Surface Mount Magnetic Reed Switch Set, Standard Gap, DPDT, CX2, Brown
29PD-B | GI-29PDB
Please sign in to view pricing and availability and to add to cart.
Accessories
Overview
Specifications
Documents
Product Overview
This series offers a standard gap of 1 inch, a wide gap of up to 1 1/2 inches and an extra wide gap of 2 inches and can be installed on a steel surface with a minimum gap penalty. The “P” style is a pre-wired switch with 2 feet of conductor cable. A broad range of mounting brackets are also available.
Main Features
- This Versatile Series Sets The Industry Standard For Co mmercial and Light Industrial Applications
- Surface Mount Magnetic Contacts
- 24" #22 AWG 2 Conductor Jacketed Lead on 29PA
- Longer Leads on 29PA Upon Request
- Covers, Spacers and Mounting Hardware Included
- Built-in E.O.L. Resistors and Diodes Upon Request
- Supervisory Loops and Dummy Terminals Upon Request
- Switches and Magnets Available Separately
- Colors: White, Brown, Gray
- Private Labeling Upon Request
General Information
Name: GRI 29PD-B 29P Series Standard Surface Mount Magnetic Reed Switch Set, Standard Gap, DPDT, CX2, Brown
Category: George Risk Industries, Intrusion, Alarm Contacts, Magnetic Contacts
UPC Code: 697625045129
Country of Origin: United States. Country of origin is subject to change.
Specifications
-
ADI Part Number GI-29PDB Brand Name George Risk Industries Manufacturer George Risk Industries Manufacturer Part Number 29PD-B Product Model 29PD-B Product Name 29PD-B Magnetic Contact Product Series 29P Product Type Magnetic Contact
-
Connectivity Technology Wired Contact Form CX2 Power Consumption 5W Standard Gap 1"
-
Application/Usage Commercial, Industrial Color Brown Material Steel
-
Input Current 250mA Input Voltage 175V DC Power Source DC
-
Contact Type DPDT, Open Loop Installation Type Commercial Length 24"
-
Limited Warranty Lifetime
-
Certifications & Standards UL and ULC approved Country of Origin US Features Armored Cable Lead Protection
